| SPECIFICATIONS: |
| AC Voltage: |
100mV to 600V ±(0.5% + 0.5V)
(Phase to Neutral and Phase to Phase) |
| AC Current(via clamps): |
100mA to 1200A ±(0.5% + 0.1~5A*) |
| AC Power: |
0 to 9.999MW, MVA & MVAR ±(1% + 8W~ 80k*) (True, Apparent and Reactive Power)
*Range dependent |
| Programmable Input Ratios |
| CT: |
1 to 600 |
| PT: |
1 to 1000 |
| Wiring Systems: |
Single Phase, 2 and 3 Wire
Three Phase, 3 and 4Wire |
| Power Factor: |
0.01 to 1 ±(0.04) |
| Phase Angle: |
±180° ±1° |
| Frequency: |
45 to 65Hz ±0.1Hz |
| Data Logging |
|
| Sample Interval: |
2 seconds to 7200 seconds (2 hours) |
| Date/Time: |
Real time yy/mm/dd/hr/min/sec |
| Media: |
2G SD Card (included) |
| Format: |
CSV for Import from Excel |
| Other Functions: |
Auto and manual current ranges, Data Hold |
| IEC Rating: |
1010 CATIII 600V |
| Dimensions |
|
| Instrument: |
225(H) x 125(W) x 64mm, 1049gm |
| AC Clamps: |
210 x 64 x 33mm, 522gm (Jaw opening: 86mm) |
| Battery: |
8 xAA or (included) external power supply |
| Accessories Included: |
4 x Test leads with Alligator Clips, 3 x 1200Amp Clamp Adaptors, 2G SD Card, Mains power adaptor, Carry Bag & User Manual. |
